Description
This 18Gbps HDMI Extender can extend HDMI HD signal and IR control signal to a distance up to 230ft / 70m via a single CAT6/6a cable, which can achieve zero-delay, uncompressed long-distance transmission be[1]tween the transmitter and receiver. Video resolution is up to 4K2K@60Hz. It supports EDID copy pass-through function between the source device and display device. It supports POC function. This Extender can be widely used in multi-media conference halls, TV teaching and large-screen displays.
Technical Specifications
HDMI2.0b and HDCP 2.2 compliant
· Support 18Gbps video bandwidth
· Support video resolution up to 4K2K@60Hz RGB/YCBCR 4:4:4
· The transmission distance can be extended up to 230ft / 70m via a single CAT6/6a cable
· Support HDR, HDR10, HDR10+, Dolby Vision, HLG
· Support bi-directional IR control signal pass-through
· Audio formats: LPCM 7.1, Dolby True HD, DTS HD Master
· EDID copy pass-through function between the source device and display device
· Support ARC and audio de-embedding, audio is output through the optical fiber port of the receiver
· Support bi-directional POC (Power over Cable) function
· Compact design for easy and flexible installation
