Description
The 4K60 4:4:4 HDMI matrix is a multi-purpose high-speed video processing system. It can be configured for 2 different output modes. It can perform as a 4×4 seamless matrix switcher, as a 2×2, 4×1 or 1×4 etc video wall solution. It also features a web browser interface module for control and configuration of the matrix when used stand-alone or with a third party control system. Control options include front-panel push buttons, IR remote control, RS-232 interface and TCP/IP.
Technical Specifications
· Compliant HDMI 2.0b
· Compliant HDCP 2.2 and HDCP 1.4
· Features 2 operational modes: - 4×4 Matrix (seamless switch) - Video wall (2×2, 4×1 or 1×4 etc configuration)
· Seamless video switching
· Video inputs support all industry standard video resolutions including VGA-WUXGA (up to 1920×1200 @60Hz) and 480i-4K (3840 x 2160 @60Hz 4:4:4, 4096 x 2160 @60Hz 4:4:4)
· HDMI outputs support upscale or downscale to any resolution, up to 4096 x 2160@60Hz 4:4:4
· Support LPCM, DD, DD+, DTS, Dolby TrueHD, DTS HD-master pass-through
· Advanced EDID management
· Web interface module for control and configuration of Matrix
· Control via front panel, IR, RS-232 and TCP/IP
· 3rd Party drivers available for all major home control brands
Download the technical specification sheet here - LINK
